DS18 Monoblock Subwoofer Amplifier Class D 2000W Pro Car Audio Bass ZR2000.1D

DS18 Monoblock Subwoofer Amplifier Class D 2000W Pro Car Audio Bass ZR2000.1D

This Listing Includes:

• (1) DS18 Amplifier ZR1000.1D


• (1) Owner's Manuel


• (1) Bass Knob


• (1) Bass Knob connection


• (4) Phillips Head Screws


• (2) Wrenches

The DS18 ZR Series amps are made to power all your subwoofers with incredible sound acuity and massive bass frequency responses. Easily tuned, this ZR2000.1D comes with Lowpass and Subsonic filters to help you set to the perfect frequency for your music preference!

The included bass knob will help you attenuate your bass with a quick turn of the dial to tune in your bass volume with every song you play.

FEATURES:

• Digital Class D Subwoofer Monoblock


• MAX Wattage: 6000w Peak @ 1-Ohm


• Frequency Response: 10-220 Hz


• Signal to Noise Ratio: Greater Than 95Db


• Power and Ground Terminal: 0 Ga


• Minimum Impedance: 1 Ohm

SPECIFICATIONS:

POWER

• Total Watts (Peak): 6000W


• RMS Power @ 4 ohm: 800W


• RMS Power @ 2 ohm: 1300W


• RMS Power @ 1 ohm: 2000W

AUDIO

• Frequency Response: 10-220Hz


• Signal to Noise Ratio: Greater than 95dB


• Efficiency @ 4ohm: 80%


• Damping Factor: 220


• Input Impedance: 20K ohm


• Total Harmonic Distortion (THD): 0.01%


• Low Level Input Range: 0.2-6V


• High Level Input: Yes


• Selectable X-Over: LPF Fixed


• X-Over Filter Range: 40-180Hz


• Bass Boost Range: 0-12db


• Bass Boost Frequency: 30-80hz


• Infrasonic Filter: 10-50hz


• Phase Selector: 0-180

DIMENSIONS:

• Overall Length: 19.13"


• Overall Wide: 7.24"


• Overall Height: 2"


• Heatsink Length :17.75"


• WEIGHT: 8.1 lbs
